CPU BX - 5A1

CPU BX - 5A1

Hãy trở thành người đầu tiên đánh giá sản phẩm này( 0)
310.000 đ
CPU BX - 5A1
Mã sản phẩm: CPU BX - 5A1
Giá: 310.000 VNĐ
Tình trạng: Còn hàng
Lượt xem: 6357
Bảo hành: 12 tháng
    large_04_2017_44_bx-5ut-mach-dieu-khien

    Technical parameters:



    Product model BX-5A1
    Product status The latest 5th generation products,put into market on March 28,2012.
    Control area Single color32K:2048*16 1024*32 672*48 512*64
    Dual color16K:1024*16 512*32 336*48 256*64
    Memory storage 2MByte
    Screen types All kinds of  single and double colors LED screen
    Software function Screens cluster management/multi-program/multi-areas display/multi-languages
    Program type Normal/Shared program
    Program quantity Support 128 programs,8 areas for each program
    Area  type Image/text/animation/lunar calendar/digital clock/analogue clock
    /timer/temperature/temperature & humidity
    Frame mode Most advanced colorful / magic graphics frame/Area frame
    Background Support colorful and active background
    Time mode Analogue clock/digital clock/timing and counting-down timer (support multi-groups)
    Communication mode S232/RS485,stanard RS232,customized RS485
    Interface 2 nos T8 and 4 nos T12
    Sensors supported Temperature /humidity
    Remote control Remote control program/lock screen/brightness adjustment/power on/off /screen test
    Bright regulation 16 grades brightness, manual and auto-timing adjustment/remote control
    Power on/off mode Auto-timing powered on/off /remote control
    Voltage 5V (3.5V~6V wide voltage)
    Maximum power ≤1W
    Temperature -40°C~80°C
    Secondary development Provide the DLL and corresponding demos
    Software LedshowTW2014
    User manual LEDshowTW 2014 software user manual
