1. The maximum loading capacity is 1.3 million pixels.
2. Support expending memory by U-disk.
3. HDMI high-definition video input & output.
4. Support HD video decoding, 60Hz frame rate output.
5. Support HDMI HD video zoom, no need video processor.
6. Equipped with Wi-Fi, Mobile APP management.
|
Features |
Parameters |
|
Control Range |
Resolution: 1.3 million pixels (1280*1024), Widest 3840 pixel, highest 2048 pixel |
|
Gray Scale |
256-65536 (adjustable) |
|
Basic Functions |
Video, Pictures, Gif, Text, Office, Clocks, Timing, etc. Remote, Temperature, Humidity, Brightness, PM Value, etc. Support Synchronized picture auto-zooming, Playing Live Screen Without Video Processor |
|
Video Format |
HD video hard decoding, 60Hz frame rate output. AVI, WMV, RMVB, MP4, 3GP, ASF, MPG, FLV, F4V, MKV, MOV, DAT, VOB, TRP, TS, WEBM, etc. |
|
Image Format |
Support BMP, GIF, JPG, JPEG, PNG, PBM, PGM, PPM, XPM, XBM, etc. |
|
Text |
Text editing, Image, Word, Txt, Rtf, Html, etc. |
|
Document |
DOC, DOCX, XLSX, XLS, PPT, PPTX, etc. Office2007 Document format |
|
Time |
Classic Analog Clock, digital clock and various of clock with image background |
|
Audio output |
Double track stereo audio output |
|
Memory |
8GB Flash Memory, Expanding memory by U-disk |
|
Communication |
100M/1000M RJ45 Ethernet, Wi-Fi, 3G/4G, LAN, USB |
|
Working Temp |
-40℃-80℃ |
|
Port |
IN：12V Power Adapter*1, 1Gbps RJ45*1, USB 2.0*1, Test Button*1, GPS, 3G/4G(Optional), Sensor port*1, HDMI*1 OUT：1Gbps RJ45*1，AUDIO*1 |
|
Power |
18W (12V DC power supply) |
