Function |
Parameters |
|
Work with sending card |
Dual-mode sending box，Asynchronous sending card, Synchronous sending card, Video processor of VP series. |
|
Module type |
Compatible with all common IC module, supported most PWM IC module. |
|
Supports any scanning method from static to 1/64 scan |
|
|
Communication method |
Gigabit Ethernet |
|
Control range |
Recommend：65,536 pixels (128*512) Outdoor module width ≤256, Indoor module width ≤128 |
|
Multi-card connection |
Receiving card can be put in any sequence |
|
256~65536 |
|
|
Smart setting |
A few simple steps to complete the smart settings, through the screen layout can be set to go with any alignment of the screen unit board |
|
Test functions |
Receiving card integrated screen test function, Test display brightness uniformity and display module flatness. |
|
Communication distance |
Super Cat5,Cat6 network cable within 80 meters |
|
Port |
5V DC Power*2,1Gbps Ethernet port*2, HUB75E*12 |
|
Input voltage |
4V-6V |
|
Power |
5W |
